Fitting the dome housing (typically referring to the port of a hemispherical waterproof enclosure) to an underwater camera is a task requiring meticulous care and patience, as any oversight may result in water ingress damaging the equipment.
Below is a detailed, step-by-step installation guide for your reference.

Core principles: Cleanliness, lubrication, alignment, sealing

Step One: Preparatory Work
1.Select an appropriate environment:
This procedure should be carried out in a clean, dust-free, well-lit indoor environment. Airborne sand particles or dust are the sworn enemies of sealing rings. It is advisable to lay a soft cloth over the work surface to prevent scratching the ball cover and equipment.
2.Prepare tools and materials:
Dome and camera housing.
Silicone grease: Specifically designed for lubricating and maintaining seals on underwater photography equipment. Never use Vaseline, oils, or other non-specialized lubricants, as these will corrode silicone seals.
Microfibre cloth: For cleaning.
Air blower: To remove fine dust particles.
If required: Lens paper or cleaning solution (for cleaning the inner and outer surfaces of the dome).

Step Two: Thoroughly inspect and clean
This is the most crucial step, capable of preventing 90% of water ingress risks.
1. Inspect the main O-ring:
Location: Within the port groove of the waterproof housing or the edge groove of the ball cover.
2. Inspection Items:
Integrity: Gently run your fingers along the entire circumference of the seal to ensure there are no gaps, cracks, flattened sections, or distortions.
Cleanliness: Carefully feel the surface with your fingertips to ensure no hair, dust, or grit particles are adhering to it.
3. Cleaning the seal ring:
If dust is present, carefully blow it away using compressed air.
If the seal is significantly soiled, it may be removed with extreme care. Clean it using clean water and a microfibre cloth, then allow it to air dry completely before reinstalling it in the correct groove. Ensure it is not twisted or misaligned.
4. Cleaning the seal groove:
Utilise compressed air and a microfibre cloth to ensure the interior of the recess where the seal is positioned is also completely free of dust.
5. Cleaning the dome cover:
Use a microfibre cloth and lens cleaning solution (if required) to clean both the inner and outer surfaces of the dome cover. Ensure no fingerprints, water marks or contaminants remain, as these may adversely affect imaging quality.

Step Three: Lubricate the Sealing Ring
1. Apply a small amount of specialized silicone grease to your fingertip and spread it evenly and thinly across the entire surface of the sealing ring.
2. Purpose: To lubricate, thereby assisting the sealing ring to compress uniformly under pressure and to trap any minute dust particles that may have escaped detection.
3. Caution: Do not apply excessively; a thin layer suffices. Excess silicone grease may be forced into the interior under pressure, potentially contaminating the lens hood or lens itself.

Step Four: Install the dome cover
1. Alignment:
Align the connector of the ball cover with the port of the waterproof housing. Typically, alignment marks or a bayonet-style design will be present. Ensure the force is applied vertically and evenly, without tilting.
2. Pressing:
Apply even pressure with both hands to press the ball cover smoothly into the waterproof housing port. You will feel the seal being compressed and typically hear a faint “pop” or feel the latch engage.
For screw-in ball covers, hand-tighten clockwise ensuring threads align smoothly. Never use tools such as spanners to over-tighten, as this may damage threads or crush the seal.
3. Locking mechanism:
Should your ball cover feature a locking ring, after pressing the cover firmly into place by hand, rotate the locking ring clockwise until it clicks securely into position. Again, ensure a firm, snug fit without applying excessive force, and verify that all latches or locking devices are fully engaged.

Step Five: Final Inspection and Pre-Launch Testing
1.Visual inspection: Examine from all angles whether there are any visible gaps between the ball cover and the housing, and whether the sealing ring is uniformly exposed in a small circumference.
2. Land Test (Optional but Recommended):
Note: This test carries risks; proceed only under safe conditions.
Take the camera housing with the dome lens attached (without the camera unit) to a bucket or safe body of water. Submerge it several centemetres deep for several tens of seconds. Upon removal, immediately dry the housing thoroughly with a dry cloth, paying particular attention to the connectors and locking mechanisms. Open the housing and carefully inspect the interior for any moisture vapour or water droplets. If the interior is completely dry, the installation is successful. Should any trace of water be detected, cease immediately and review all steps to identify the cause.

●●● Summary of Important Notes ●●●
*The steps for cleaning and inspecting the seals must be repeated before each use in water.
*Under no circumstances should non-specialized lubricants be applied to the sealing rings or ball covers.
*Apply force evenly and vertically during installation to prevent skewed pressure from distorting the seal ring.
*Send the seals to a specialist organization for maintenance or replacement at regular intervals (annually or according to usage frequency).
*After submersion, thoroughly rinse the camera housing and dome with fresh water, paying particular attention to the buckle and seal areas to remove salt and grit. Ensure all openings are closed before rinsing.
*When storing, the ball cover should be separated from the housing. The sealing ring should be lightly coated with silicone grease and placed loosely in the groove, avoiding prolonged compression.
