What are the properties of cold mirrors?
Reflects@400 - 690nm
Transmit@750 - 1200nm
AOI: 0°or 45°

What is the size range of the cold & hot mirrors from Yutai Optics?
Max:200*200mm
Min:3*3mm
Please contact our service staff if you need larger or smaller cold& hot mirrors

What are the applications of cold mirrors?
Entertainment lighting: reduce the heat accumulation of stage or photography lighting to prevent the equipment from overheating.
Projection system protection: prevent infrared rays from damaging the liquid crystal panel or DMD chip.
Microscopy illumination optimization: reduce the risk of thermal damage to the samples.

What are the differences between cold mirrors and hot mirrors?
Properties	Cold Mirror	Hot Mirror
Reflection band	VIS light (400-700nm)	IR light (>700nm)
Transmission band	IR light	VIS light
Role	Retain visible light and eliminate heat	Block heat and retain visible light
Coating	Multilayer dielectric coating (TiO2/SiO2)	Metallic coating or dielectric coating
