Biochemical Analyzer Filters

Biochemical analyzers (e.g., enzyme markers, spectrophotometers, blood analyzers, etc.) rely on filters to achieve high-precision optical detection, and their core role is to select specific wavelengths of light for sample analysis, while blocking interfering light to improve detection sensitivity and accuracy.
Share this:
 Facebook  Twitter  LinkedIn  Google+  Addthis
Inquiry Now
What are the common biochemical analyzer filters?
340 nm (NADH/NADPH assay)
405 nm (alkaline phosphatase ALP)
546 nm (hemoglobin assay)
380mm,410mm,510mm,578nm,
620mm,630nm,670mm,700mm

How to choose a biochemical analyzer filter?
The performance of biochemical analyzer filters directly affects the accuracy and repeatability of the test results. It is important to pay attention to it when selecting the model:
Wavelength matching (strictly against the requirements of the kit).
FWHM and OD value (balance sensitivity and anti-interference ability).
Durability (hard coating + bezel design for automated instruments).

For high-end applications (e.g. ultra-micro detection), it is recommended to choose ultra narrow band (FWHM<5 nm) + OD6 filters; for routine detection, it is recommended to choose wide band (20~40 nm) + OD4 to reduce the cost.
